Features
• 40,000 lbs capacity;
• ETL certified AMGO power unit comesstandard;
• Mechanical self-locking safety device with air-driven lock release;
• Standard primary safety locks and cable-slack protection system;
• Cable-driven system utilizing areo standard, high-quality cable ;
• Hydraulic cylinders are designed and manufactured to a high standard, utilizing high-quality oil seals and a compensation valve;
• Non-skid diamond platforms with two widths setting.
Specifications
| Model | PRO-40 | |
|---|---|---|
| Lifting Capacity | 40,000 Ibs | |
| Lifting Time | 183s | |
| Overall Length (Inc Ramps) | A | 366 1/8" |
| Outside Edge of Crossbeams | B | 307 1/16" |
| Overall Width | C | 151 1/2" |
| Width Between Columns | D | 133 15/16" |
| Max. Lifting Height | E | 75 3/8" |
| Max. Lock Height to top of runway | 72 3/16" | |
| Overall Height | F | 92" |
| Minimum Height | G | 10 3/8" |
| Max. Underneath Height | H | 66 5/16" |
| Max. Lock Underneath Runway | 63 3/16" | |
| Drive-Thru Clearance | I | 119 13/16" |
| Width Between Runways | J | 46" 54 1/16“ |
| Outside Edge of Runways | K | 101 7/8" 110” |
| Gross Weight | 8,503bs | |
| Motor | 2.0HP |
Detailed Image
Oil-water separator and solenoid air valve are installed on the power side column.
ETL certified AMGO power unit.
Standard primary safety locks and cable-slack protection system.
Hydraulic cylinders are designed and manufactured to a high standard, utilizing high-quality oil seals and a compensation valve.
Non-slip diamond platforms with two-width setting.
Optional Air line kits-All AMGO four post lifts are designed to use the air line kits for rolling jack. Kits No.:40106A
Optional rolling jack with 20,000lbs capacity: RJ-20A- pneumatic.
Shipping Information
1 units/package, packing measurement (LxWxH): 317 5/16" x 29 15/16" x 40 9/16". Packed with Power Unit.
2 units/package, packing measurement (LxWxH) : 317 5/16" x 29 15/16"x 79 15/16"
After the machine is pulled out from the container, use the forklift to lift the machine from the middle position.
Use a forklift to lift up one end of the machine about 2"-5" from the ground, and pull the machine out from the container with the assistance of lifting belt or other cables.
