Description
Features
• Dual direct drive hydraulic cylinders made to high standards
• Super-Asymmetric Arm design, makes finding the lift point of the car easier
• Single point safety release, allows the operator to disengage both columns simultaneously
• Self lubricating UHMW Polyethylene sliders and bronze bushings
• Clear floor design, provides unobstructed floor use
• Overhead safety shut off device measures vehicle damage
• Stackable rubber pads and 1.5″, 2.5″, 5″
• Five-year Warranty on Steel Components, Three-year Warranty on Hydraulic Parts and Two Years on Electrical Components
Model | OH-10 |
Lifting Capacity | 10,000 lbs (4,536 kg) |
Lifting Time | 57S |
A: Lifting Height | 71 1/2″ ~ 80 1/2″ (1815~2044mm) |
B: Overall Height | 142 1/2″ /150 1/2″ (3621/3821mm) |
C: Overall Width | 135″ (3428mm) |
D: Drive Thru Clearance | 99 1/2″ (2528mm) |
E: Width Between Columns | 112 1/4″ (2850mm) |
F: Minimum Pad Height | 3 1/2″ (90mm) |
Motor | 2.0HP / 220V/60Hz, Single Phase |
Gross Weight | 1,623 lbs (736 kg) |
Detailed Images
- Single point safety release makes it easier for operators to unlock both column locks from one column.
- Lifting arm lock automatic release device, high strength gear rack, more stable and safer.
- Super asymmetric arms allow you to load different vehicles in an asymmetric or symmetric configuration. Self-lubricating UHMW polyethylene sliders, rubber door guards to protect your vehicle.
- Dual hydraulic direct-driven cylinders
- The stackable rubber pads package with 1.5″, 2.5″, 5″ extension adapters.
- Optional Saddle adaptors perfect choice for wide size SUV vehicles. Kits No.:20802
- Optional Height Extension Kits With this kits,the height can be adjusted from 3821mm(150 1/2″)to 4431mm(174 1/2″) Kits No.:20902(OH-9) Kits No.:21002(OH-10)
- Optional Width Extension Kits With these kits the width between posts is adjusted from112 1/4″ (2850mm) to 118 1/8″(3000mm). Kits No.:20906(OH-9 OH-10)
- Optional LED light for all two post lifts. Floor plate two post lifts LED light,Kits No.:20101; Clear floor two post lifts LED light,Kits 20101 plus extension cable 20103
